Sintering mesh fluidized plate\filter is carefully welded with multi-layer sintering mesh. Each weld bead and joint shall be firmly bonded together to ensure perfect sealing. Sintered mesh filter is generally composed of flanges and multi-layer sintered mesh, filtration accuracy and compressive strength can be adjusted as needed, compared with the traditional filter pressure resistance is stronger, high temperature resistance is better, due to the special structure of multi-layer sintered mesh, easy to clean and backwash cleaner. Our company's sintered mesh filter raw materials after strict inspection, accurate filtration accuracy, material standards, screen does not fall off, weld beads are firm and uniform without defects such as leakage welding.
　　Interface:
　　215, 220, 222, 226 and other rubber ring interfaces, M20, M24, M28, M30, M36 and other threaded interfaces, triangular interfaces, flange interfaces, special-shaped interfaces, etc.
　　Features:
　　1. Simple structure, convenient maintenance and easy cleaning.
　　2, strong structure, not easy to damage long life.
　　3, temperature range (-200℃ to 600℃ continuous use).
　　4, corrosion resistance, acid and alkali resistance, high pressure resistance.
　　5, high filtration accuracy (1μ m-300 microns)
　　6. Stable structure, no deformation of mesh during filtration, and more accurate filtration.
　　Applications:
　　1. Food industry: yeast and mold removal from alcohol and carbonated beverages, clarification and filtration of sugar solution, clarification of fruit wine and juice, sterilization and filtration, fermentation products and bacterial separation.
　　2. Medical treatment and medicine: manufacturing of pyrogen-free purified water, sterilization of infusion, injection and preparation, filtration and sterilization of blood filtration, plasma separation, serum, tissue culture and other biological agents, filtration of raw materials and intermediates.
　　3. Chemical industry: clarification of chemical raw materials, sterilization filtration, filtration and clarification of various chemicals such as water solvents, acids and alkalis, separation of emulsified oil and water, emulsion filtration, filtration of high viscosity polymer spinning solution, and filtration of coating impurities.
　　4. Electronics industry: manufacturing of ultrapure water, purification and filtration of various solvents and gases in semiconductor manufacturing, purification of agents and solvents for optical disk manufacturing.
　　5, petroleum, machinery: all kinds of oils, such as fuel oil, lubricating oil, hydraulic oil, cutting oil filtration purification, oil-water separation, production links in the separation of intermediate products.
　　6. Biochemistry: removal of miscellaneous bacteria in fermentation process, concentration and separation of bacteria, filtration of bacteria-like bodies.
　　7, water treatment: suspended solids in water, fine particles and bacteria removal.
